RFID ID Badges

RFID has become the preferred ID badge technology for various types of data collection systems (door access, time clocks, point of sale, and computer sign-on).

Other than the non-standard insertion smart cards, contactless RFID offers the highest level of security granted by an ID badge and is not easily duplicated. RFID card readers last longer than those using magnetic stripe or barcode technology since they do not have exposed read heads or moving parts.

FEATURES

Light, durable, and low cost
Available with stretch rope or key chain, easy to carry
Colors, sizes, and crafts are available
LF chips, HF chips, and UHF chips are available
Operating range up to 100mm (depending on various parameters)
Wide application: Access control management, membership management, parking management, child pickup, cashless payment, social interaction, etc.

AVAILABLE CHIPS

LF 125kHz Chips

Chip Name	Protocol	Capacity	Frequency
TK4100	/	64 bits	125 kHz
EM4200	/	128 bits	125 kHz
EM4305	/	512 bits	125 kHz
T5577	/	330 bits	125 kHz

HF 13.56 MHz Chips

Chip Name	Protocol	Capacity	Frequency
Ntag213	ISO14443A	180 byte	13.56 MHz
Ntag215	ISO14443A	540 byte	13.56 MHz
Ntag216	ISO14443A	924 byte	13.56 MHz
MIFARE Classic 1K	ISO14443A	1 KB	13.56 MHz
MIFARE Classic 4K	ISO14443A	4 KB	13.56 MHz
MIFARE Ultralight EV1	ISO14443A	80 byte	13.56 MHz
MIFARE Ultralight C	ISO14443A	192 byte	13.56 MHz
ICODE SLIX	ISO15693	1024 bits	13.56 MHz

860~960 MHz UHF Chips

Chip Name	Protocol	Capacity	Frequency
Alien H3	ISO18000-6C	512 bits	860~960 MHz
Impinj Monza 4	ISO18000-6C	96 bits	860~960 MHz
UCODE G2iL	EPCglobal Class1Gen2	128 bits	860~960 MHz

Parameters

Item	rfid id badges
Material	PVC,PET
Chip	LF chips/ HF chips
Frequency	125 kHz or 13.56MHz
Protocol	ISO14443A
Color	black, yellow, blue, etc
Size	85.5*54 or custom
Memory	Depend on chips
Reading distance	0-10m
Write Endurance	100000 times
Working Temperature	-25°C to 65°C
Data Retention Time	10 years
Printing Options	Silk-screen printing, Laser Engraving, CMYK full color, Pantone, etc.
Crafts Available	Logo or number printing, Bar code, QR code, etc.
Samples	Free samples are available upon request
